96V100Ah(32S1P)
Battery Type: LiFePO4
Cell Type: Square Aluminum
Rated Voltage: 102.4V
Rated Capacity: 100Ah
Battery Power: 10.24KWhh
Application area:Base station power supply, home energy storage, photovoltaic energy storage category
Customized Inquiry：+8613662633933
For specific parameters, please check the product description below.
Product Detail
| MODEL | 96V100Ah(32S1P) |
| Rated Voltage | 102.4V |
| Rated Capacity | 100Ah |
| Battery Power | 10.24KWh |
| Battery Type | LiFePO4 |
| Crycling Lifespan | 2000Cycles |
| Max. Charging Voltage | 116.8V |
| Over Discharging Voltage | 80V |
| Standard charge cu ent | 20A |
| Max. Charging Current | 50A |
| Peak Charging Current | 55A |
| Standard discharge current | 20A |
| Max. Discharging Current | 50A |
| Peak Discharging Current | 60A |
| Weight | 100Kg |
| Dimension（L*W*H） | 900*530*203.5mm |
| Application area | Base station power supply, home energy storage, photovoltaic energy storage category |
| Communication-CAN / RS485 / USB / | RS485/CAN/RS232 |
| Storage Condition | 0-25°C |
| Charging Temp. Range | 0-45°C |
| Discharging Temp. Range | 0-60°C |
| Transportation | UN38.3,MSDS |
| Safety | IEC 62619: 2017,EN IEC 61000-6,UL1973 GB31241-2014（CQC）UL2054/un38.3/KCMSDS/RoHS/CE/UL60950/RCM/PSE/BIS/REACH |
Features
1.Implement one-button power on
2. Support the combination of old and new batteries
3. Customize the BMS communication protocol
4.Integrated design, easy installation
5.System cabinet design/battery cluster management
6.Customizable design/safe and reliable/space saving
7. Can remotely monitor, real-time upload device status, support remote upgrade
8.High power tolerance
